Stainless Steel Metal Push On/Off Switch 12V Round Button 16mm (BU0072) Products
We are sorry but the product is out of stock, please check back after few days.
| Name | Stainless Steel Metal Push On/Off Switch 12V Round Button 16mm |
| Code | BU0072 |
| Price | Rs.390.00 |
| In Stock | No |
| Package | THT |
Product Details
Specifications:
- High quality metal material & IP65 waterproof protection can be used in wet or dusty environment.
- Optional Colour: Iris; Blue
- LED voltage: 12VDC
- Hole size required: Approx. 0.63" / 16mm
- Latching switch: Push it, ON; Push it again, OFF
- Touch Configuration: 1NO 1NC
- Switch rating: 5A / 250VAC
- Working temperature: -20 ~ +55degree Celsius
- Mechanical life: 1,000,000 cycles
- Electrical life: 200,000 cycles
- Panel thickness: Approx. 1-10mm
- Protection level: IP65, IK10
- Operation type: Latch
- LED rating: 12VDC 15mA
- LED pattern: Ring indicator
- Touch material: Silver alloy
- Button material: Stainless Steel
