48V 20A Battery Charger eBike (Glue WP Type) (BA0217) Products
We are sorry but the product is out of stock, please check back after few days.
| Name | 48V 20A Battery Charger eBike (Glue WP Type) |
| Code | BA0217 |
| Price | Rs.3,200.00 |
| In Stock | No |
| Package | BATTERY |
Product Details
Specifications:
| Input | 100-240VAC,50/60HZ | Input Plug |
EU US UK AUS JP Korea Italy Brazil
India South Africa |
| Output |
4.2V/ cell
10S 42V3A |
Charge mode | CC--CV Mode |
| Led Indicator |
Red--charging;
Green--full charge |
Protection |
Over-current, Over-voltage,
Short-circuit, Polarity reverse |
| Suitable Battery | Lithium Ion battery pack | Efficiency | >82% |
| Output connector | customized(as below) |
MTBF |
50000hrs |
| Hi-Pot | 3000VAC/60S |
Storage Temperature |
-40ºC~ +80ºC |
| Operating Temperature | -20ºC~ +50ºC |
Lead time |
sample: 3-5 days |
| Certification | CE FCC GS CB PSE KC SAA |
|
|
|
|
|
Features:
- Short-circuit protection, charger o/p current automatically when short-circuit
- Overload protection: Charger o/p current limited automatically when overload
- Reverse polarity protection: It will shut down when the wire is connected, charge DC fuse or remove the fault
- 3-stage charging mode: CC(constant current), CV(constant voltage) and float stage
- Reliable, elegant, Small size, light, with cooling fan
- Charging state: TWO LED display
- Multiple plugs can be selected
Charging operation
- Step 1, Examine and make sure rated voltage of battery is conforming to output voltage of charger.
- Step 2, Connect correctly the charger and the battery.
- Step 3, Examine and make sure mains supply voltage is conforming to input voltage of the charger.
- Step 4, Connect mains supply and the battery, watch to see if the indicator is on and the cooling fan is working when charging.
- Step 5, if the charger refuse to work, turn off mains supply immediately and check all the connecting cables between mains supply, the battery and the charger.
