2.4G Tranceiver 2Mbps BK2421 RDM70 CT800 (MD0661) Products
We are sorry but the product is out of stock, please check back after few days.
Name 2.4G Tranceiver 2Mbps BK2421 RDM70 CT800
Code MD0661
Price Rs.260.00
In Stock No
Product Details

The main pros of this module:

  • High data speed 2Mbps (A7105 CC2500 is 512K)
  • Module power at 5dbm and distance can reach 120 meters. NRF24L01, A7105, CC2500 transmission power at 0dbm(1mw)Distance around 20 meters

Specification:

  • 2.4Ghz ISM Band free to use
  • FSK/GFSK modulation
  • 1Mbps/2Mbps on air data speed
  • Programmable power:-35, -25, -15, -5, 0, 5 dBm
  • 14mA power consumption at 0 dBm
  • 21mA power consumption at 1Mbps data speed
  • Three level adjustable length payload, length from 1 till 32 bytes, or one level adjustable length payload, length from 1 till 255 bytes
  • Automatic data handle
  • Capable to do 1:6 star network communication, can receive from six different channel at the same time
  • Power supply from 1.9V till 3.6V
  • Low power consumption, 3uA at power down mode, and 410 uA at standby mode
  • 4 pins SPI at 8Mbps clock speed
