Overview

• The 2SC2240 is a transistor for low frequency and low noise applications. This device is designed to lower noise figure in the region of low signal source impedance, and to lower the pulse noise. This is recommended for the first stages of Equalizer amplifiers.

Features

• Type Designator: 2SC2240
• Material of Transistor: Si
• Polarity: NPN
• Maximum Collector Power Dissipation (Pc): 0.3 W
• Maximum Collector-Base Voltage |Vcb|: 120 V
• Maximum Collector-Emitter Voltage |Vce|: 120 V
• Maximum Emitter-Base Voltage |Veb|: 5 V
• Maximum Collector Current |Ic max|: 0.1 A
• Max. Operating Junction Temperature (Tj): 150 °C
• Transition Frequency (ft): 50 MHz
• Collector Capacitance (Cc): 3 pF
• Forward Current Transfer Ratio (hFE), MIN: 200

Supplier link: https://alltransistors.com/adv/pdfdatasheet_toshiba/2sc2240.pdf
