Banana Pro/Pi Camera Module a high definition camera module for Banana Pro/Pi. The camera module connects to the CSI connector on the Banana Pro/Pi board. It provides high sensitivity, low crosstalk and low noise image capture in a small and lightweight design.

Features:

• Image sensor: Omnivision 5640 CMOS image sensor in an auto-focus module with integral IR filter (650±10nm)
• Still resolution: 5 Megapixels
• Active array size: 2592×1944
• Max frame rate: 1080P 30fps@24Mhz
• Picture formats: JPEG PNG YUV420 RGB888
• Video formats: Raw h.264
• Image control functions: Automatic exposure control (AEC)
• Automatic white balance (AWB): Automatic black level calibration(ABLC)
• Automatic band filter
• Mirror and flip: Temp range
• Operating: -30℃ to 70℃
• Stable image: 0℃ to 50℃
• Lens size: 1/4”
• Dimension: 36 x 32 x 10mm
