The CYL05F 4H-E100 Ethernet Surge Protector is designed to safeguard Ethernet-based networks and devices from lightning strikes, power surges, and transient overvoltage. With a high surge protection capacity of up to 10kA, it ensures stable data transmission while protecting sensitive networking equipment in outdoor and industrial installations.

Key Features:

• High surge protection capacity up to 10kA
• Protects Ethernet devices from lightning-induced surges
• Maintains network signal integrity with low insertion loss
• Plug-and-play inline installation
• Rugged metal housing for long-term durability
• Reliable grounding for effective surge dissipation

Specifications:

• Model: CYL05F 4H-E100
• Protection Type: Ethernet / Network surge protector
• Surge Current Capacity: 10kA (8/20 μs waveform)
• Network Type: 10/100 Mbps Ethernet
• Connector Type: RJ45 (Female to Female)
• Nominal Voltage: 5V (data line)
• Insertion Loss: ≤0.3 dB
• Response Time: ≤1 ns
• Shielding: Metal enclosure with ground terminal
• Operating Temperature: -40°C to +85°C

Applications:

• Ethernet CCTV and IP cameras
• Network switches and routers
• Outdoor and pole-mounted network equipment
• Industrial Ethernet systems
• Data and communication lines
