Nema23 Stepper Motor 72Ncm 2A 6-wire cable 57BYGH207 (MT0129) Products
We are sorry but the product is out of stock, please check back after few days.
| Name | Nema23 Stepper Motor 72Ncm 2A 6-wire cable 57BYGH207 |
| Code | MT0129 |
| Price | Rs.3,160.00 |
| In Stock | No |
Product Details
Specifications:
- Step angle: 1.8°
- Voltage (V): 12
- Current (A): 0.4
- Resistance (Ohms): 30
- Inductance (mH): 60
- L0 Dimension (mm): 56
- L1 Dimension (mm): 21
- Holding Torque (kg.cm): 8.0
- Control Wires: 6
- Insulation Resistant: 500V DC 100 MOhm Min
- Insulation Strength: 50Hz 1Minute 500V Min
- Ambient Temperature: -20°C~+50°C
- Temperature Rise: 80°C Max.
- Radial Play: 0.02mm Max.
- End Play: 0.1-0.3mm
