The NEMA 34 Stepper Motor (86HZ156-120) delivers a massive 11Nm holding torque, making it perfect for CNC machines, industrial automation, and robotics. With an 8-wire configuration, it supports both bipolar and unipolar wiring for flexible control. Built for high accuracy, reliability, and smooth operation, this motor ensures powerful and precise movement for demanding applications.

Specifications:

• Operating Voltage: 12-24VDC
• Step Angle: 1.80°
• Length: 156mm
• Current: 4.2A
• Resistance/Phase: 1.25ohm
• Holding Torque: 11Nm
• Winding Type: Hybrid
