SIMCom presents an ultra compact and reliable wireless module-SIM900. This is a complete Quad-band GSM/GPRS module in a SMT type and designed with a very powerful single-chip processor integrating AMR926EJ-S core, allowing you to benefit from small dimensions and cost-effective solutions.

Featuring an industry-standard interface, the SIM900 delivers GSM/GPRS 850/900/1800/1900MHz performance for voice, SMS, Data, and Fax in a small form factor and with low power consumption. With a tiny configuration of 24mm x 24mm x 3 mm, SIM900 can fit almost all the space requirements in your M2M applications, especially for slim and compact demands of design.

Features:

• Quad-Band 850/900/1800/1900 MHz
• GPRS multi-slot class 10/8
• GPRS mobile station class B
• Compliant to GSM phase 2/2+
  • Class 4 (2 W @850/ 900 MHz)
  • Class 1 (1 W @ 1800/1900MHz)
• SAIC (Single Antenna Interference Cancellation) support
• Dimensions: 24 x 24 x 3 mm
• Weight: 3.4g
• Control via AT commands (GSM 07.07 ,07.05 and SIMCOM enhanced AT Commands)
• SIM application toolkit
• Supply voltage range : 3.2 ... 4.8V
• Low power consumption: 1.0mA (sleep mode&BS-PA-MFRMS=9)
• Operation temperature: -40°C to +85 °C
