Specifications:

• Motor Type: Brushless motors are commonly used in RC projects due to their efficiency and power-to-weight ratio.
• Waterproof Depth: 20m
• KV Rating: This indicates the number of revolutions per minute (RPM) per volt. Higher KV motors are faster but provide less torque, while lower KV motors offer more torque but are slower.
• Thrust: The amount of thrust the motor can produce, typically measured in grams or ounces. This depends on the propeller size and the battery voltage.
• Current Draw: The amount of current the motor draws under load, which affects the battery life and the electronic speed controller (ESC) requirements.
• Propeller Compatibility: The size and pitch of the propeller that the motor can effectively drive.
• Mounting Options: The mounting pattern and hardware required to attach the motor to your RC frame.

Clockwise (CW) Motor:

• KV Rating: 480KV
• Voltage: 12-24 V
• Current Draw: 20A max
• Weight: 162g approx.
• Dimension: 260mm Diameter / 60mm Propeller Diameter
• Material: Motor 304 Stainless Steel Bearing + Aluminum alloy shell PLA PC Propeller

Counterclockwise (CCW) Motor:

• KV Rating: 480KV
• Voltage: 12-24 V
• Current Draw: 20A max
• Weight: 162g approx.
• Dimension: 260mm Diameter / 60mm Propeller Diameter
• Material: Motor 304 Stainless Steel Bearing + Aluminum alloy shell PLA PC Propeller
