USB Socket Male Type A Plug Metal Housing Shell (CN0015) Products
| Name | USB Socket Male Type A Plug Metal Housing Shell |
| Code | CN0015 |
| Price | Rs.60.00 |
| In Stock | Yes |
| Package | SMD |
Product Details
Specifications:
- Type A - Male, 4Pin
- Housing materials: PBT+30% G.F(UL 94 V-0)
- Contact materials: copper alloy
- Shell materials: steel
- Contact current rating: 1.5A max. per pin
- Voltage rating: 30V (DC)
- Contact resistance: 30mΩ max.
- Dielectric withstanding voltage: 500V AC(rms) for 1 minute
- Insulation resistance: 100MΩ min.
- Operating temperature: 0°C to +50°C
- USB Plug Male Standard Connector for Computer Use, with Stainless Steel Shield .
- Size: App. 37mm x 12mm x 4.5mm
