The XL6009 DC-DC switching boost converter is capable of driving a 4A load with excellent line and load regulation. It is an efficient switching regulator and the output efficiency is significantly higher in comparison with the popular boost regulators. At higher input voltages, the regulator operates at a switching frequency of 400kHz thus allowing the overall board size to be smaller and space-saving.

Features

• Input voltage: 3 - 32V
• Output voltage: 5 - 35V (adjustable)
• Output current: Maximum output current 4A
• Note: The higher the voltage, the load current increases.
• Efficiency of this regulator up to < 94>
• Load regulation: 0.5%
• Voltage regulation: 0.5%
• Adjustable potentiometer onboard for output voltage adjustment.
• Non - isolated constant voltage module.
• Non - synchronous rectification.
• Short circuit proportion: Current limiting since the recovery.
• Dimension: 45x20x14mm (LxWxH)
