FEATURES

• Low forward voltage drop

• Low leakage current

• High forward surge capability

• Solder dip 275 °C max. 10 s, per JESD 22-B106

TYPICAL APPLICATIONS

For use in general purpose rectification of power supplies, inverters, converters, and freewheeling diodes application.

MECHANICAL DATA

Case: DO-41 (DO-204AL), molded epoxy body Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade

Terminals: matte tin plated leads, solderable per J-STD-002 and JESD 22-B102 E3 suffix meets JESD 201 class 1A whisker test Polarity: color band denotes cathode end

Supplier link: https://www.vishay.com/docs/88503/1n4001.pdf
