The 24VDC Miniature Relay is a compact and versatile electromagnetic switch designed for controlling AC or DC loads in automation, electronics, and DIY projects. Its small form factor, high switching capacity, and reliable operation make it ideal for industrial and hobbyist applications.

Key Features:

• High Switching Capacity: Supports up to 10A at 250VAC or 30VDC
• Compact Design: Small footprint for tight installations
• Electromagnetic Operation: Reliable on/off switching with low control current
• Versatile Applications: Suitable for industrial control, home automation, and electronics projects
• Durable Construction: Long mechanical and electrical lifespan

Specifications:

• Type: Miniature Electromagnetic Relay
• Coil Voltage: 24V DC
• Contact Rating: 10A at 250VAC / 10A at 30VDC
• Contact Configuration: SPDT or DPDT (depending on model, typically SPDT)
• Number of Pins: 4 or 5-pin (depending on configuration)
• Mounting Type: PCB or socket mount
• Operating Temperature: -40°C to +85°C
• Insulation Resistance: ≥100MΩ (DC500V)
• Dielectric Strength: 1500VAC (coil-contact)

Applications:

• Industrial automation control
• Home and building automation systems
• Electronic switching circuits
• DIY electronics and robotics projects
• Timer, alarm, or relay logic circuits
