Specification

• Supply voltage:  3.3V
• Supply Current: Current: <120mA>
• Peak current: <140mA>
• Fingerprint image time: <1>
• Window size: 14x18 mm
• Matching mode: Match mode (1:1)
• Search mode (1: N)
• Signature File: 256 bytes
• Template files: 512 bytes
• Storage capacity: 200max
• Safety level: five (from low to high: 1,2,3,4,5)
• False Accept Rate (FAR): <0>
• False Reject Rate (FRR): <1>
• Search time: <1>
• PC Interface: UART (TTL logic level) or USB2.0 / USB1.1
• Communication baud rate (UART): (9600 x N) bps where N = 1 ~ 12 (default value N = 6, ie 57600bps)

Working Environment

• Temperature: -20 ° to +50 °
• Relative Humidity: 40% RH-85% RH (non-condensing)

Storage Environment

• Temperature: -40 ° to +85 °
• Relative humidity: 85%
• Dimensions (L x W x H): 56 x 20 x 21.5mm
