Ensure accurate axis homing and reliable end-stop detection with the Horizontal Limit Switch Module, designed specifically for 3D printers and motion control systems. Its horizontal mounting design allows easy installation in compact spaces while providing precise and consistent switching performance.

Key Features:

• Horizontal Mount Design: Ideal for tight or low-profile installations on 3D printers.
• Accurate End-Stop Detection: Ensures precise homing and reliable axis positioning.
• Stable Mechanical Operation: Provides consistent triggering with minimal bounce.
• Durable Construction: Designed for long service life under repeated use.
• Easy Installation: Pre-mounted switch on PCB with mounting holes and standard connector.

Specifications:

• Type: Limit Switch Module
• Mounting Orientation: Horizontal
• Switch Type: Mechanical micro switch
• Output: Normally Open / Normally Closed (model dependent)
• Operating Voltage: 3.3V – 5V (typical for 3D printer control boards)
• Application: 3D printer end-stop detection

Applications:

• X / Y / Z axis homing on 3D printers
• Motion limit detection in CNC and laser machines
• DIY and custom motion control projects
