Specifications:

• Resistance at 100C: 970–1030Ω
• Dissipation Factor: 1.5mW/C min in still air
• Thermal Time Constant: 21 seconds max. in still air
• Insulation Resistance: 100MΩ (DC=100V)
• Maximum operating current: 8mA max.
• Rated operating current: 2mA
• Rated Power: 50mW max
• Temperature measurement range: -55C~+180C
• Storage time: 2 Years (Room temperature, relative humidity <60>

Applications:

• Motion control temperature sensor, temperature sensing and controls in drives and motors, spindles, inverters and control systems, etc.
• Industrial automation control equipment
• Precision circuit and crystal oscillator temperature compensation
• Temperature compensation of silicon semiconducting devices
• Temperature compensation of instrumentation amplifier
• A/D converter temperature compensation
• Micro motor timing control
• Automobile temperature detection and control
• Medical equipment temperature detection and control
• Linear PTC thermistors applications also include transmission, engine oil and coolant, heating system, overheating protection, amplifiers, power supplies, transducers, telemetry, computers, magnetic amplifiers, thermometry, meteorology, temperature regulation and over-temperature protection
