The LM237 and LM337 are adjustable 3-terminal negative-voltage regulators capable of supplying in excess of –1.5 A over an output voltage range of –1.2 V to –37 V. They require only two external resistors to set the output voltage and one output capacitor for frequency compensation.

Features:

• Output Voltage Range Adjustable
  From –1.2 V to –37 V
• Output Current Capability of 1.5 A Max
• Input Regulation Typically 0.01% Per Input-
  Voltage Change
• Output Regulation Typically 0.3%
• Peak Output Current Constant Over Temperature
  Range of Regulator
• Ripple Rejection Typically 77 dB
• Direct Replacement for Industry-Standard LM237
  and LM337

Package: TO-220

Datasheet: Datasheet
