Load Cell 1Kg (MD0514) Products
We are sorry but the product is out of stock, please check back after few days.
| Name | Load Cell 1Kg |
| Code | MD0514 |
| Price | Rs.480.00 |
| In Stock | No |
| Package | MODULE |
Product Details
Specifications:
- Range weight: 0-1kg
- Recommended control voltage: 5-10V (maximum 10V)
- Dimensions: 12.7 x 12.7 x 80mm
- Two holes for M5 bolts
- Two holes for M4 bolts
Pinout wires:
- Red: + Excitation
- White: - Signal
- Black: - Excitation
- Green: + Signal
Note: The signals from this load cell can not be read with an Arduino. This requires an additional signal amplifier, namely the HX711 Dual-channel 24-bit AD Conversion Weighing Sensor Module for Load Cell
