The Omron MY4N-J is a reliable 4PDT (4 Form C) plug-in electromagnetic relay designed for industrial control and automation systems. Featuring a 220VDC coil, this relay is ideal for high-voltage DC control circuits while providing stable switching performance for both AC and DC loads.

Key Features:

• 220VDC Coil Voltage: Designed for high-voltage DC control applications
• High Contact Rating: Supports loads up to 5A
• 4PDT Contact Configuration: Enables control of multiple circuits simultaneously
• 14-Pin Plug-In Design: Compatible with Omron MY-series relay bases
• Industrial-Grade Construction: Ensures long service life and dependable operation

Specifications:

• Model: MY4N-J
• Coil Voltage: 220VDC
• Contact Rating: 5A @ 240VAC / 5A @ 28VDC
• Contact Type: 4PDT (Four Pole Double Throw)
• Number of Pins: 14
• Mounting Type: Plug-in (socket mount)
• Mechanical Life: ≥10⁷ operations
• Electrical Life: ≥10⁵ operations (at rated load)
• Operating Temperature: -40°C to +85°C
• Insulation Resistance: ≥100MΩ (DC 500V)
• Dielectric Strength: 2000VAC (coil to contacts)

Applications:

• Industrial automation and relay logic circuits
• PLC control and switching systems
• Power distribution and signal control
• Timers, alarms, and control panels
