MF RC522 is suitable for a variety of applications based on for ISO/IEC 14443A standard and requires low-cost, small size, high performance and single-supply contactless communication. For Three-table; on-board units; public transportation terminals; portable handheld devices; contactless public telephones.

Features

• Serial power supply voltage (VCC): 5V
• RX serial port reception
• TX serial port transmission
• GND power ground
• Product model: For MIFARE RC522
• Sleep current: <80uA>
• Peak current: <30mA>
• Working frequency: 13.56MHz
• Card reading distance: 0~45mm
• Interface: UART TTL
• Baud rate: 115200
• Data transmission rate: up to 10Mbit/s
• Ambient operating temperature: -20~80°C
• Storage temperature: -40~85°C
• Humidity: Relative humidity 5% - 95%
• Agreement: for ISO14443A compliant, for Mifare1 S50, S70
