LC-GSM-SIM800C USB to GSM is a quad-band GSM/GPRS module with stable performance, compact appearance and high cost performance, which can meet the various needs of customers. Integrated USB to serial port chip, you can plug directly into the computer to debug. SIM800C operates at GSM/GPRS 850/900/1800/1900MHz which support to be used worldwide. It can transmit voice , SMS information and data information with low power consumption, and can be applied to different design requirements of many compact product.

Features:

• Support quad-band, universal worldwide;
• Automatically connect to the network. The module is powered on automatically to connect to the network, no need to press the button to power on, saving time and more convenient;
• Support Bluetooth:IEEE802.15 Bluetooth standard, 2.4GHz working frequency band;
• On-board original SIM800C GSM/GPRS module;
• On-board CH340T USB to serial port chip, easy to install and high compatibility;
• Self-elastic SIM card slot design, can be used 2G/3G/4G Micro SIM and Nano card;
• Support SMS messaging and provide management software;
• Provide full set instruction of host computer source code (c#, vb) for reference;
• Support GPRS data transmission under 2G network, which can be applied to mobile meter reading and other occasions;
• It works with LED indicator, when there is no network, no SIM card or SIM card is inserted, the LED light flashes quickly in 1 second interval, and it flashes every 3 seconds if normally work.

Specifications:

• Product Name:  SIM800C USB to GSM Module
• Product Number: LC-GSM-SIM800C
• Working Voltage: 5VDC
• Working Temperature range: -20℃~85℃
• Working Humidity range: 0%-95%RH
• Size of Controller: 70*27*6mm
• Size of Antenna: 50*17*11mm
