Specification:

• Tail configuration: Wiring terminal
• Switch Rating: 3A/250VAC
• Contact resistance: ≤50mΩ
• Insulation resistance: ≥1000mΩ
• Dielectric intensity: 2000VAC
• Operation Temperature: -20℃ ~ +55℃
• Mechanical life: 500,000 cycles
• Electrical life: 50,000 cycles
• Panel thickness: 1 - 10mm
• Nut torque: 5 - 14Nm
• Operation pressure: About 4N
• Operation stroke: About 1.5mm
• Protection level: IP67, IK08
• Mounting Cut Hole: 16mm
• Head Diameter: 19mm
• Operation Type: Momentary
• Switch Contact: 1NO (Normally Open)
• Head Shape: Flat
• Terminal Type: Screw
• Body Material: Stainless Steel (SS is much more resistant to wear and abrasion)
• Button Material: Stainless Steel
• Base: PA66
• Color: Silver / Chrome
