TIP122 NPN Darlington Bipolar Power Transistor 100V 5A (DI0173) Products
We are sorry but the product is out of stock, please check back after few days.
| Name | TIP122 NPN Darlington Bipolar Power Transistor 100V 5A |
| Code | DI0173 |
| Price | Rs.100.00 |
| In Stock | No |
| Package | TO-220 |
Product Details
Designed for general−purpose amplifier and low−speed switching applications.
Features:
- Type Designator: TIP122
- Material of Transistor: Si
- Polarity: NPN
- Maximum Collector Power Dissipation (Pc): 65 W
- Maximum Collector-Base Voltage |Vcb|: 100 V
- Maximum Collector-Emitter Voltage |Vce|: 100 V
- Maximum Emitter-Base Voltage |Veb|: 5 V
- Maximum Collector Current |Ic max|: 5 A
- Max. Operating Junction Temperature (Tj): 150 °C
- Forward Current Transfer Ratio (hFE), MIN: 1000
Datasheet:: https://www.onsemi.com/pdf/datasheet/tip120-d.pdf
