Three-mode design for a digital oscilloscope and multimeter, featuring one-button mode switching, automatic waveform acquisition, time base calibration, data storage, data export, language selection, shutdown time setting, adjustable backlight, data transmission port, signal output setting, and storage functions. Easy to operate, enhancing work efficiency. Widely used in automotive, industrial equipment, sensors, heavy-electrical equipment, rectification, and low) yoltage systems.

Specifications:

• Display: 3.05 inch IPS full viewing angle color screen
• Ranging: Auto/Manual
• Material: ABS+TPE
• Update Rate: 3 Times/Second
• Ture RMS: yes
• Data Hold: yes
• Backlight: yes
• Low Battery Indication: yes
• Auto Power Off: yes
• Dimension: 177x89x40mm

Oscilloscope Specifications:

• Bandwidth: 50MHz
• Sampling method: real-time sampling
• real-time sample rate: 280MSa/s
• Channels: 2
• input coupling: AC/ DC
• input resistance: 1MS,@16pf
• Probe attenuation: X1, X10
• Sample rate range: 1.5Sa/s -280MSa/s
• Waveform interpolation: (sinx)x
• Sweep speed range: 10ns/div-20s/div
• Time Base Accuracy: 20ppm
• record length: Max 128Kbyte
• sensitivity: 20mV/div-10V/div
• Displacement range: 4 cells (positive and negative)
• Analog Bandwidth: 50MHz
• low frequency response: >10Hz
• Rise Time: <10ns>
• DC Gain Accuracy: 13%

Multimeter Specifications:

• DC Voltage (V): 1000.0mV/ 250.00V/ 25.000V/ 2.5000V
• DC Voltage (mV): 250.00mV/ 25.00mV
• AC Voltage (V): 750.0V/ 250.00V/25.000V/ 2.5000V
• AC Voltage (mV): 250.00mV/ 25.00mV
• Frequency response of ACV: 40Hz-1kHz
• DC Current (A): 10.000A/2.5000A
• DC Current (mA): 25.000mA/250.00uA
• AC Current (A): 10.000A/2.5000A
• AC Current (HA/mA): 25.000mA/250.00uA
• Frequency response of AC Current: 40Hz-1kHz
• Resistance: 250.00Ω/ 2.5000kΩ/ 25.000kΩ/ 250.00kΩ/2.5000MΩ/ 25.000MΩ/ 250.0MΩ
• Capacitance: 999nF/ 99.99n/ 999.9nF/ 9.999uF/ 99.99uF/ 999.9uF/ 9.999mF/ 99.99mF
• Frequency: 99.99Hz/ 999.9Hz/ 9.999kHz/ 99.99kHz/ 999.9kHz
• Diode: yes
• Continuity: yes
