Specifications

• Type: Touch panel (Resistive)
• Working Voltage: 5V DC
• Display Size: 2.8 inch SPI Serial
• Display Area: 36.72(W) x 48.96(H)mm
• Physical Size: 8.5 x 4.8cm
• Driver Element: a-Si TFT active matrix
• Pixel Arrangement: RGB vertical stripe
• Controller Chip: Arduino Compatible (Such as ILI9341, ST7789, SPFD5408, etc.)
• Backlight: White LED <button></button>
• Viewing Direction: 6 o'clock
• Colour Depth: 262K / 65K <button></button>
• Resolution: 240RGB x 320 Dots
• Logic Compatibility: 5V compatible (built-in level shifter for 3.3V or 5V logic) <button></button>

Features

• Efficient SPI Interface: Uses only a few digital pins to communicate, leaving more pins available for sensors and actuators.
• Integrated Touch Control: Includes a resistive touch screen for creating user-friendly interfaces and menus. <button></button>
• Universal Logic Support: Safely connects to both 3.3V microcontrollers (like ESP32/STM32) and 5V boards (like Arduino Uno/Mega).
• High-Quality Visuals: RGB vertical stripe arrangement and 262K color support ensure crisp text and vivid images. <button></button>
• Common Applications:
  • Handheld diagnostic tools and meters
  • Smart home control terminals
  • Embedded systems with graphical user interfaces (GUI)
  • Interactive DIY gaming consoles
