The 4–20mA RTD PT100 SBW Temperature Sensor Transmitter Module is a high-precision temperature measurement and signal conversion module designed for industrial and automation applications. It converts the resistance signal from a PT100 RTD sensor (Single Bridge Wire – SBW) into a standard 4–20mA current output, ensuring reliable and noise-immune long-distance transmission.

With a measurement range of 0 to 100°C, this module is ideal for environments where accurate temperature monitoring, stability, and compatibility with PLCs, controllers, and industrial instruments are required.

Features

• Supports PT100 RTD temperature sensors (SBW configuration)
• Converts temperature signal to standard 4–20mA current output
• High accuracy and excellent long-term stability
• Strong anti-interference performance for industrial environments
• Suitable for long-distance signal transmission
• Compact and easy-to-integrate module design
• Low power consumption
• Reliable operation in harsh industrial conditions

Specifications

• Sensor Type: PT100 RTD (Single Bridge Wire – SBW)
• Temperature Range: 0 – 100°C
• Output Signal: 4 – 20mA
• Power Supply: DC 12V – 24V
• Output Load Resistance: ≤ 500Ω (typical, depends on supply voltage)
• Accuracy: ±0.5% FS (typical)
• Operating Temperature: -20°C to +60°C
• Response Time: ≤ 1s (typical)
• Mounting Type: Module / PCB mount
• Signal Type: Analog current loop

Applications

• Industrial temperature monitoring systems
• PLC and DCS temperature input systems
• HVAC temperature control
• Process automation and control
• Laboratory and testing equipment
• Boilers, heaters, and thermal systems
• Data acquisition and logging system
