Specification

• Operating Speed (4.8V no load): 20sec / 60 deg
• Operating Speed (6.0V no load): 16sec / 60 deg ( no load)
• Stall Torque (4.8V): 9kg/cm
• Stall Torque (6.0V): 10kg/cm
• Operation Voltage : 4.8 - 7.2V (6V recommended)
• Gear Type: All Plastic Gears
• Stable and shock proof double ball bearing design
• Dead band width: 5 µs
• Temperature range: 0 ºC - 55 ºC.
• Control System: Analog
• Operating Angle: 120degree
• Required Pulse: 900us - 2100us
• Dimension : 40.7 × 19.7 × 42.9 mm

Features

• The connection cable is thicker
• Equips high-quality motor
• High resolution
• Accurate positioning
• Fast control response
• Constant torque throughout the servo travel range
• Excellent holding power

Wire Connection

• RED – Positive
• Brown – Negative
• Orange – Signal

* Product Images are shown for illustrative purposes only and may differ from actual product
