PT2272 is a remote control decoder paired with PT2262 utilizes CMOS technology. It has 12-bit of tri-state address pins providing a maximum of 531,441 (or 312) address codes; thereby, drastically reducing any code collision and unauthorized code scanning possibilities. PT2272 is available in several options to suit every application need: variable number of data output pins, latch, or momentary output type.

Features:

• CMOS Technology
• Low Power Consumption
• Very High Noise Immunity
• Up to 12 Tri-State Code Address Pins
• Up to 6 Data Pins
• Wide Range of Operating Voltage: VCC=4~15V
• Single Resistor Oscillator
• Latch or Momentary Output Type
• Available in DIP and SOP

Package: DIP-18

Datasheet: http://www.princeton.com.tw/Portals/0/Product/PT2272.pdf
