Features:

• Long distance APP remote control via Bluetooth;
• Support almost every kind of one-wire or two-wire LED driver IC ;
• Brightness adjustable, With 180 kinds of patterns and 8 kind of color adjustable patterns;
• Creatively usingfrom-image-to-effect method for user toDIYany effect;
• Support setting pixel number and segments number, able to control up to 2048pixels;
• DC5V~24V widerangeworking voltage, preventing reverse connection of power supply;
• User setting saving

App control:

 Both IOS version and Android OS version are available.

• Requires IOS version 10.0 or later;
• Requires Android OS version 4.4 or later;
• Search”Led Chord”in App Store or Google pay or scan this QR code to download and install the App

Specifications:

• Working temperature : -20~60 Degrees Celsius
• Working Voltage : DC5V~24V;
• Working Current :20mA~130mA;
• Remote distance :30 Meters;
• Product size : 85mm*45mm*22mm;
• Product weight : 40g ;
• Certificates : CE, RoHS

APP Operations:

1. Make sure you have turned on Bluetooth on your phone;

2. Open the APP, drag to refresh the device list, select device name “SP107E” to connect the controller, once connected you will able to rename your controller;

3. Select RGB order and IC type;

4. Adjust the pixel number;

5.Press ENTER.

Audio Input:

There are two ways to input the audio signal on SP107E, AUX IN, and Build-IN microphone;
