IC0321 - TLC2272 Advanced LinCMOS Rail-To-Rail Operational Amplifier SOP-8 (Original)

TLC2272 Advanced LinCMOS Rail-To-Rail Operational Amplifier SOP-8 (Original) (IC0321) Products

Name	TLC2272 Advanced LinCMOS Rail-To-Rail Operational Amplifier SOP-8 (Original)
Code	IC0321
Price	Rs.120.00
In Stock	Yes
Package	SOP

Product Details

The TLC2272 and TLC2274 are dual band quadruple operational amplifiers from Texas Instruments. Both devices exhibitable to rail output performance for increased dynamic range in single or split supply applications.TheTLC227x family offers 2MHz of bandwidth and 3 V/μs of slew rate for higher speed applications. These devices offer comparable AC performance while having better noise, input offset voltage, and power dissipation than existing CMOS operational amplifiers. TheTLC227x has a noise voltage of 9 nV/√Hz, two times lower than competitive solutions.

Features

Output Swing Includes Both Supply Rails

Low Noise: 9 nV/ √Hz Typical at f = 1 kHz

Low-Input Bias Current: 1-pA Typical

Fully-Specified for Both Single-Supply and Split- Supply Operation

Common-Mode Input Voltage Range Includes Negative Rail

High-Gain Bandwidth: 2.2-MHz Typical

High Slew Rate: 3.6-V/μs Typical

Low Input Offset Voltage: 950μV Maximum at TA = 25°C

Micromodel Included

Performance Upgrades for the TLC272 and TLC274

Available in Q-Temp Automotive
